Single Sight Glass

Allied Valves India is a leading Single Sight Glass Manufacturer and Supplier in Ahmedabad, Gujarat. We supply compact, borosilicate sight glasses for flow visibility to process industries across India.

What is a Single Sight Glass?

A Single Sight Glass is a flanged pipeline fitting with a borosilicate glass window that allows visual inspection of process fluid flow, color, and clarity directly within the pipeline. Built in Carbon Steel, SS 304, or SS 316, with ASME B16.5 RF flanged end connections, it’s designed for compact, robust, and maintenance-friendly installation. Available in sizes 15mm to 250mm. Explore our Sight Glass range or compare with our Double Window Sight Glass.

Key Features of Single Sight Glass

• Single borosilicate glass window for flow observation
• Body: Carbon Steel, SS 304, or SS 316
• Glass material: Borosilicate
• End connection: ASME B16.5 RF flanged ends
• Pressure rating: Class 150#
• Working temperature: Up to 200°F (93°C)
• Hydro test pressure: Body 70 PSIG
• Glass packing: PTFE
• Fasteners: Mild Steel or Stainless Steel
• Size range: 15mm to 250mm (1/2″ to 10″)

Applications of Single Sight Glass

Widely used in chemical processing, food & beverage, water treatment, and general process piping where visual confirmation of fluid flow, level, or condition is needed without interrupting the process.

Benefits of Single Sight Glass

• Enables direct visual monitoring of process fluid flow
• Borosilicate glass offers excellent clarity and chemical resistance
• PTFE packing ensures a leak-tight, durable glass seal
• Flanged ASME B16.5 connections ensure secure pipeline installation
• Compact, maintenance-friendly design simplifies upkeep
• Wide size range suits small to large pipeline diameters

Working of Single Sight Glass

The Single Sight Glass is installed in-line within the pipeline via its flanged connections, with the borosilicate glass window sealed against the body using PTFE packing. As process fluid flows through the fitting, operators can visually observe flow rate, color, clarity, or the presence of bubbles and contaminants directly through the glass, without needing to interrupt flow or open the pipeline for inspection.

Why Choose Allied Valves?

Allied Valves India manufactures Single Sight Glasses with durable borosilicate glass and a wide choice of body materials to suit demanding process applications. With ASME B16.5 flanged connectivity, PTFE sealing, and years of industry experience, we deliver fittings built for dependable, long-term performance.
